High Speed Powder Metallurgy Equipment HDH Titanium Powder Making Machine

Name: High Speed Powder Metallurgy Equipment HDH Titanium Powder Making Machine
Brand: EasyFashion Industry
Price: 1 USD

Brand Name : EasyFashion Industry

Model Number : /

Certification : CE/CB/CQC/FCC/ISO

Place of Origin : China

MOQ : 1 set

Price : /

Payment Terms : L/C, D/A, D/P, T/T, Western Union, MoneyGram

Supply Ability : 15~25 sets per year

Delivery Time : 120~200 days

Packaging Details : 1.Outer package:Standard wooden cases 2.Inner package:Strenth films & Styrofoam

Commodity : titanium powder making equipment

titanium powder making equipment : 50-600kg

Norminal furnace temperature : 950c

Max.furnace temperature : 1600c

Rated power : 60-240kw

Contact Now

Titanium Powder Production Equipment

1.Introduction

The professional titanium powder making equipment adopts hydrogenationdehydrogenation (HDH) process. This specialized powder machine allows titanium sponge to fiercely react with hydrogen at certain temperature. When hydrogen content in titanium sponge is more than 2.3%, brittle titanium hydride is formed. Through heat

treatment at 700℃, most interstitial hydrogen is subsequently removed to product titanium powder.

2.Advantages

1. Cost containment

Instead of removing out of the titanium powder equipment, hydrogenated material is milled in shielding gas environment and directly moves to dehydrogenation process, thus minimizing pollution risk and energy consumption on temperature adjustments.

2. High efficiency

This titanium powder making machine covers hydrogenation, milling and dehydrogenation processes, thus offering a continuous manufacture workflow. Therefore, customers benefit from outstanding efficiency

and production rate.

3.Technical Parameters

Model	EF- ZKT50	EF-ZKT100	EF-ZKT200	EF-ZKT300	EF-ZKT450	EF-ZKT600
Nominal feeding capacity (kg)	50	100	200	300	450	600
Nominal furnace temperature (℃)	950	950	950	950	950	950
Max. furnace temperature (℃)	1600
Temperature accuracy (℃)	≤±5
Rated power (kW)	60	75	120	165	200	240
Rated voltage of power supply (V)	380
Rated heating voltage (V)	Depends on design (External transformer is available in all design. )
Max. vacuum degree (Pa)	≤6.67 (Empty furnace in cool environment)
Pressure rising rate (Pa/24h)	≤50
Working area dimension (W× H×L) (mm)	300×300 ×400	300×300 ×500	450×400 ×670	450×400 ×850	500×500 ×1000	600×600 ×1300
Temperature controlling system	Shimaden programmable controller
Vacuum system	Rotary vane vacuum pump + Roots vacuum pump
Degreasing system	Water ring pump

Product Tags:

powder metallurgy equipment

powder metallurgy manufacturing process

High Speed Powder Metallurgy Equipment HDH Titanium Powder Making Machine Images
